Siemens GNF Safety Disconnect Switch, General Duty, Non-Fusible, 240 VAC/250 VDC, 7.5 hp at 240 VAC, 3-Phases, 30 A, 3-Poles, 3-Wires, 100 kA RMS Short Circuit, 3PST, Highly Visible Red Handle Actuator, NEMA 1, IP20, Indoor, Surface Mount, 7.1 Inch W x 8.2 Inch H x 3 Inch D, Galvanized Steel
| Actuator Type | : | Highly Visible Red Handle |
| Amperage Rating | : | 30 A |
| Contact Form | : | 3PST |
| Dimensions | : | 7.1 Inch W x 8.2 Inch H x 3 Inch D |
| Enclosure Type | : | NEMA 1, IP20, Indoor |
| Material | : | Galvanized Steel |
| Mounting Type | : | Surface |
| Number of Poles | : | 3 |
| Number of Wires | : | 3 |
| Power Rating | : | 7.5 hp at 240 VAC, 3 Phase |
| Series | : | GNF |
| Short Circuit Rating | : | 100 kA RMS |
| Type | : | General Duty, Non-Fusible |
| Voltage Rating | : | 240 VAC/250 VDC |
- Cover interlock
- Tangential knockouts through 600 A for easy conduit lineup
- Quick-make, quick break operating mechanism that ensures positive operation
- Visible blade, double-break switch action
- Positive two or 3-point mounting
- Highly visible red handle grip
- Side hinged door that opens 180 deg for easier wiring
- Handle and cover padlocking provisions
- Suitable for use on 3-phase motor loads
- Service entrance labeled
Standard/Approvals: UL 98 Listed
Application: Construction, Industrial and Residential
